2022 HIGHLIFTER TIRE & WHEEL

T I R E & WH E E L 2 0 2 2 Email orders to Orders@Parts-Unltd.com Phone orders to 800-369-1000 Fax orders to 800-369-1060

2 - - PASSION DRIVEN PERFORMANCE We are proud to introduce High Lifter Tire & Wheel, a strategic addition to High Lifter Products. The High Lifter group has acquired a dedicated and experienced ATV and UTV tire and wheel design team to greatly elevate our tire and wheel offering. Our team has been specifically testing, developing and manufacturing state of the art ATV and UTV tires and wheel for over 30 years. The new High Lifter Tire & Wheel team has continued to develop innovative new products and combined iconic brands to assemble a comprehensive High Lifter branded tire and wheel line addressing a wide range of applications, traction options and value. There are several things we love most about this business, but two items are most important to us; introducing new products and getting out to ride at cool places nationwide. We’ve been doing both for a long time and hope to see you on the trails!

• Continued evolution of the iconic Outlaw tire line! • Next generation specs; super deep 2.0”-2.5” pre-grooved, “dual stage” tread lugs and beefy square shoulder combined with aggressively siped and stepped center lug that will shed mud and stay clean • 10” tread width provides a 2” wider footprint than narrow Ag style treads for superior traction and flotation at a competitive weight • Super deep, notched shoulder lugs bite in the ruts • Overlapping tread at center and flexible 8-ply carcass for smooth transitional trail use ® T I R E S - - 3 OUTLAW MAX SIZE PLY RATING TREAD DEPTH (INCHES) MAX LOAD CAPACITY @ 24 PSI TIRE WEIGHT PARTS UNLIMITED PART # 28X10R-14 8 1.50 - 2.00 1,185 LBS 45.1 LBS 0320-1315 30X10R-14 8 1.50 - 2.00 1,341 LBS 49.5 LBS 0320-1326 32X10R-14 8 1.50 - 2.00 1,530 LBS 53.9 LBS 0320-1316 32X10R-15 8 1.50 - 2.00 1,491 LBS 52.8 LBS 0320-1327 33X10R-15 8 1.50 - 2.00 1,599 LBS 53.9 LBS 0320-1328 33X10R-18 8 1.75 - 2.50 1,488 LBS 45.8 LBS 0320-1317 33X10R-20 8 1.75 - 2.50 1,425 LBS 49.7 LBS 0320-1318 35X10R-20 8 1.75 - 2.50 1,602 LBS 54.5 LBS 0320-1319 35X10R-22 8 1.75 - 2.50 1,530 LBS 52.8 LBS 0320-1320 37X10R-22 8 1.75 - 2.50 1,716 LBS 59.4 LBS 0320-1321 37X10R-24 8 1.75 - 2.50 1,632 LBS 58.3 LBS 0320-1322 40X10R-24 8 1.75 - 2.50 1,941 LBS 70.4 LBS 0320-1323 SEE VEHICLE LABEL OR OWNERS MANUAL FOR OPERATING PRESSURE AVAILABLE JANUARY 2023

- - 4 T I R E S • T he 4th generation Roctane T4 is new from the inside out and features our most versatile tread design along with a smooth riding carcass • A ggressive multi-angle tread blocks and staggered shoulder blocks dig deep in loose terrain • 1 0-ply rated carcass features a wide, flat profile for surefooted and comfortable ride • Super-deep rim guard offers unmatched wheel protection ROCTANE T4 SIZE PLY RATING TREAD DEPTH (INCHES) MAX LOAD CAPACITY @ 24 PSI TIRE WEIGHT PARTS UNLIMITED PART # 27X9R-14 10 0.75 – 1.00 1,005 LBS 32.1 LBS 0320-1251 27X11R-14 10 0.75 – 1.00 1,185 LBS 37.0 LBS 0320-1252 28X10R-14 10 0.75 – 1.00 1,491 LBS 45.9 LBS 0320-1253 30X10R-14 10 0.75 – 1.00 1,341 LBS 42.0 LBS 0320-1254 32X10R-14 10 0.75 – 1.00 1,530 LBS 46.9 LBS 0320-1255 30X10R-15 10 0.75 – 1.00 1,317 LBS 42.0 LBS 0320-1256 32X10R-15 10 0.75 – 1.00 1,491 LBS 46.4 LBS 0320-1257 33X10R-15 10 0.75 – 1.00 1,599 LBS 50.4 LBS 0320-1258 35X10R-15 10 0.75 – 1.00 1,719 LBS 57.0 LBS 0320-1259 35X10R-18 10 1.125 1,680 LBS 61.6 LBS 0320-1324 37X10R-18 10 1.125 1,797 LBS 67.1 LBS 0320-1325 SEE VEHICLE LABEL OR OWNERS MANUAL FOR OPERATING PRESSURE

- - 5 • Dual sport, non-directional tread design provides a perfect blend of steering and traction performance for sport and utility applications • Tight center spacing excels on hard-pack and wide shoulder lugs pull hard in loose terrain • 8-ply rated carcass is lightweight and premium compound extends tread life • Deep rim guard protects the wheel and helps avoid pinch flats CHICANE DS SIZE PLY RATING TREAD DEPTH (INCHES) MAX LOAD CAPACITY @ 24 PSI TIRE WEIGHT PARTS UNLIMITED PART # 30X10R-14 8 0.65 1,000 LBS 36.4 LBS 0320-1260 32X10R-15 8 0.65 1,000 LBS 40.6 LBS 0320-1261 33X9.50R-15 8 0.65 1,020 LBS 40.2 LBS 0320-1262 35X9.50R-15 8 0.65 1,020 LBS 45.0 LBS 0320-1263 SEE VEHICLE LABEL OR OWNERS MANUAL FOR OPERATING PRESSURE

T I R E S - - 6 • Aggressive tread pattern with multi-angle shoulder tread • 10-ply rated, dual steel belted, heavy duty steel belt plies for maximum durability • Two-stage radial carcass provides superior uniformity and overall balance • LT-inspired UTV tire design achieves a higher level of strength and ride comfort • Super-deep rim guard defends wheels from abuse XCOMP SIZE PLY RATING TREAD DEPTH (INCHES) MAX LOAD CAPACITY @ 24 PSI TIRE WEIGHT PARTS UNLIMITED PART # 28X10R-14 10 20/32 (.625”) 1,165 LBS 40.6 LBS 0320-1246 30X10R-14 10 20/32 (.625”) 1,320 LBS 43.7 LBS 0320-1247 32X10R-14 10 20/32 (.625”) 1,520 LBS 47.8 LBS 0320-1248 32X10R-15 10 20/32 (.625”) 1,475 LBS 47.3 LBS 0320-1249 35X10R-15 10 18/32 (.563”) 1,609 LBS 54.0 LBS 0320-1250 SEE VEHICLE LABEL OR OWNERS MANUAL FOR OPERATING PRESSURE

- - 7 • Aggressive V lug design digs deep while offering a smooth ride on hard-pack • 1.5-inch tread depth in the center, up to 2.0-inch on the shoulder • 6-ply or 8-ply carcass allows for low psi operation and maximum flotation • 9-inches wide, made specifically for 20-inch wheels • Stepped, 1.5-inch to 2.0-inch tread blocks • Lightweight, aggressive, and 8-ply rated OUT&BACK MAX SIZE PLY RATING TREAD DEPTH (INCHES) MAX LOAD CAPACITY @ 24 PSI TIRE WEIGHT PARTS UNLIMITED PART # 27X10-12 6 1.50 - 2.00 470 LBS 40.6 LBS 0320-1238 27X10-14 8 1.50 - 2.00 942 LBS 39.6 LBS 0320-1239 28X10-14 8 1.50 - 2.00 1,002 LBS 44.0 LBS 0320-1240 30X10-14 8 1.50 - 2.00 1,134 LBS 48.2 LBS 0320-1241 32X10-14 8 1.50 - 2.00 1,260 LBS 53.8 LBS 0320-1242 OUT&BACK MAX’D SIZE PLY RATING TREAD DEPTH (INCHES) MAX LOAD CAPACITY @ 18PSI TIRE WEIGHT PARTS UNLIMITED PART # 33X9-20 8 1.50 - 2.00 1,092 LBS 42.9 LBS 0320-1243 35X9-20 8 1.50 - 2.00 1,236 LBS 48.4 LBS 0320-1244 36X9-20 8 1.50 - 2.00 1,335 LBS 51.3 LBS 0320-1245 ’ D SEE VEHICLE LABEL OR OWNERS MANUAL FOR OPERATING PRESSURE SEE VEHICLE LABEL OR OWNERS MANUAL FOR OPERATING PRESSURE

W H E E L S - - 8 HL23 • Unique meshed, split-spoke design • 8mm billet beadlock ring • 5/16-inch Grade 8 hardware • Factory-installed valve stem • Bolt-in Center Cap • 1,200-pound load rating • Lifetime Structural Warranty 15x7 Matte Gunmetal Grey

- - 9 HL23 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 14X7 4/137 5+2 (+38MM) MATTE BLACK 0230-1300 14X7 4/156 5+2 (+38MM) MATTE BLACK 0230-1301 14X7 4/137 5+2 (+38MM) MATTE GUNMETAL GREY 0230-1302 14X7 4/156 5+2 (+38MM) MATTE GUNMETAL GREY 0230-1303 15X7 4/137 5+2 (+38MM) MATTE BLACK 0230-1304 15X7 4/156 5+2 (+38MM) MATTE BLACK 0230-1305 15X7 4/137 5+2 (+38MM) MATTE GUNMETAL GREY 0230-1306 15X7 4/156 5+2 (+38MM) MATTE GUNMETAL GREY 0230-1307 14-INCH COLOR PARTS UNLIMITED PART # RAW 0220-0033 MATTE BLACK 0220-0034 MACHINED 0220-0035 RED 0220-0036 BLUE 0220-0037 15-INCH COLOR PARTS UNLIMITED PART # RAW 0223-0247 MATTE BLACK 0220-0038 MACHINED 0220-0039 RED 0220-0040 BLUE 0220-0041 15x7 Matte Black

W H E E L S - - 10 HL22 • Split 8-spoke design • Factory-installed valve stem • Bolt-in Center Cap • 1,000-pound load rating • Lifetime Structural Warranty 14x7 Gloss Black / Machined

- - 11 HL22 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 14X7 4/137 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1294 14X7 4/156 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1295 14X7 4/137 4+3 (+10MM) GLOSS BLACK 0230-1296 14X7 4/156 4+3 (+10MM) GLOSS BLACK 0230-1297 14X7 4/137 4+3 (+10MM) MATTE GUN METAL GREY/ MACHINED 0230-1298 14X7 4/156 4+3 (+10MM) MATTE GUN METAL GREY/ MACHINED 0230-1299 14x7 Matte Gunmetal Grey / Machined 14x7 Gloss Black

W H E E L S - - 12 HL21 • Unique 12-spoke design • Factory-installed valve stem • Bolt-in Center Cap • 1,100-pound load rating • Lifetime Structural Warranty HL21 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 14X7 4/137 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1290 14X7 4/156 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1291 14X7 4/137 4+3 (+10MM) GLOSS BLACK 0230-1292 14X7 4/156 4+3 (+10MM) GLOSS BLACK 0230-1293 20X7 4/137 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1320 20X7 4/156 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1321 20X7 5/4.5 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1322 20X7 4/137 4+3 (+10MM) GLOSS BLACK 0230-1323 20X7 4/156 4+3 (+10MM) GLOSS BLACK 0230-1324 20X7 5/4.5 4+3 (+10MM) GLOSS BLACK 0230-1325 22X7 4/137 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1326 14x7 Gloss Black / Machined

- - 13 HL21 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 22X7 4/156 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1327 22X7 5/4.5 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1328 22X7 4/137 4+3 (+10MM) GLOSS BLACK 0230-1329 22X7 4/156 4+3 (+10MM) GLOSS BLACK 0230-1330 22X7 5/4.5 4+3 (+10MM) GLOSS BLACK 0230-1331 24X7 4/137 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1332 24X7 4/156 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1333 24X7 5/4.5 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1334 24X7 4/137 4+3 (+10MM) GLOSS BLACK 0230-1335 24X7 4/156 4+3 (+10MM) GLOSS BLACK 0230-1336 24X7 5/4.5 4+3 (+10MM) GLOSS BLACK 0230-1337 14x7 Gloss Black

W H E E L S - - 14 HLA1 • Unique 12-spoke design • 10mm billet beadlock ring • 5/16-inch Grade 8 hardware • Factory-installed valve stem • Bolt-in Center Cap • 1,200-pound load rating • Lifetime Structural Warranty 14x7 Matte Machined

- - 15 HLA1 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 14X7 4/156 5+2 (+40MM) MATTE MACHINED 0230-1282 14X7 4/137 5+2 (+40MM) MATTE MACHINED 0230-1283 14X7 4/156 5+2 (+40MM) MATTE BLACK 0230-1286 14X7 4/137 5+2 (+40MM) MATTE BLACK 0230-1287 15X7 4/156 5+2 (+40MM) MATTE MACHINED 0230-1284 15X7 4/137 5+2 (+40MM) MATTE MACHINED 0230-1285 15X7 5/4.5 5+2 (+40MM) MATTE MACHINED 0230-1318 15X7 4/156 5+2 (+40MM) MATTE BLACK 0230-1288 15X7 4/137 5+2 (+40MM) MATTE BLACK 0230-1289 15X7 5/4.5 5+2 (+40MM) MATTE BLACK 0230-1319 14-INCH COLOR PARTS UNLIMITED PART # RAW 0220-0033 MATTE BLACK 0220-0034 MACHINED 0220-0035 RED 0220-0036 BLUE 0220-0037 15-INCH COLOR PARTS UNLIMITED PART # RAW 0223-0247 MATTE BLACK 0220-0038 MACHINED 0220-0039 RED 0220-0040 BLUE 0220-0041 14x7 Matte Black

W H E E L S - - 16 HL10 • Classic 8-spoke design • Factory-installed valve stem • Bolt-in Center Cap • 1,000-pound load rating • Lifetime Structural Warranty HL22 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 12X7 4/110 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1266 12X7 4/110 2+5 (-47MM) GLOSS BLACK / MACHINED 0230-1267 14X7 4/110 5+2 (+30MM) MATTE BLACK / SMOKE 0230-1268 14X7 4/156 5+2 (+30MM) MATTE BLACK / SMOKE 0230-1269 14X7 4/137 5+2 (+30MM) MATTE BLACK / SMOKE 0230-1270 14X7 4/110 5+2 (+30MM) GLOSS BLACK 0230-1271 14X7 4/156 5+2 (+30MM) GLOSS BLACK 0230-1272 14X7 4/137 5+2 (+30MM) GLOSS BLACK 0230-1273 20x7 Gloss Black / Machined

- - 17 HL22 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 15X7 4/156 5+2 (+40MM) GLOSS BLACK 0230-1274 15X7 4/137 5+2 (+40MM) GLOSS BLACK 0230-1275 20X7 4/156 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1276 20X7 4/137 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1277 20X7 4/156 4+3 (+10MM) MATTE BLACK / SMOKE 0230-1278 20X7 4/137 4+3 (+10MM) MATTE BLACK / SMOKE 0230-1279 20X7 4/156 4+3 (+10MM) GLOSS BLACK 0230-1280 20X7 4/137 4+3 (+10MM) GLOSS BLACK 0230-1281 14x7 Gloss Black 14x7 Matte Black / Smoke

W H E E L S - - 18 HL9 • Classic 8-spoke design • 10mm billet beadlock ring • 5/16-inch Grade 8 hardware • Factory-installed valve stem • Bolt-in Center Cap • 1,200-pound load rating • Lifetime Structural Warranty HL9 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 14X7 4/156 5+2 (+30MM) MATTE BLACK 0230-1250 14X7 4/156 6+1 (+50MM) MATTE BLACK 0230-1251 14X7 4/137 4+3 (0MM) MATTE BLACK 0230-1254 14X7 4/137 5+2 (+30MM) MATTE BLACK 0230-1252 14X7 4/137 6+1 (+50MM) MATTE BLACK 0230-1253 14X10 4/156 5+5 (0MM) MATTE BLACK 0230-1255 14X10 4/137 5+5 (0MM) MATTE BLACK 0230-1256 18x7 Matte Black

- - 19 HL9 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 15X7 4/156 5+2 (+30MM) MATTE BLACK 0230-1257 15X7 4/156 6+1 (+50MM) MATTE BLACK 0230-1258 15X7 4/137 4+3 (0MM) MATTE BLACK 0230-1261 15X7 4/137 5+2 (+30MM) MATTE BLACK 0230-1259 15X7 4/137 6+1 (+50MM) MATTE BLACK 0230-1260 15X10 4/156 5+5 (0MM) MATTE BLACK 0230-1262 15X10 4/137 5+5 (0MM) MATTE BLACK 0230-1263 18X7 4/156 6+1 (+50MM) MATTE BLACK 0230-1264 18X7 4/137 6+1 (+50MM) MATTE BLACK 0230-1265 14-INCH COLOR PARTS UNLIMITED PART # RAW 0220-0033 MATTE BLACK 0220-0034 MACHINED 0220-0035 RED 0220-0036 BLUE 0220-0037 15-INCH COLOR PARTS UNLIMITED PART # RAW 0223-0247 MATTE BLACK 0220-0038 MACHINED 0220-0039 RED 0220-0040 BLUE 0220-0041 15x7 Matte Black

W H E E L S - - 20 HL4 • Classic 8 spoke design with machined accents • Factory-installed valve stem • 1,000-pound load rating • Lifetime Structural Warranty 20x6.5 Gloss Black /Machined

- - 21 HL4 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 12X7 4/110 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1241 12X7 4/110 2+5 (-47MM) GLOSS BLACK / MACHINED 0230-1242 12X7 4/156 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1243 12X7 4/137 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1244 14X7 4/110 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1245 14X7 4/156 4+3 (+5MM) GLOSS BLACK / MACHINED 0230-1246 14X7 4/137 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1247 20X6.5 4/156 4+2.5 (+10MM) GLOSS BLACK / MACHINED 0230-1248 20X6.5 4/137 4+2.5 (+10MM) GLOSS BLACK / MACHINED 0230-1249 14x7 Gloss Black / Machined

W H E E L S - - 22 HL3 • Classic multi-spoke design • Factory-installed valve stem • 1,000-pound load rating • Lifetime Structural Warranty HL3 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 12X7 4/110 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1226 12X7 4/110 2+5 (-47MM) GLOSS BLACK / MACHINED 0230-1227 12X7 4/156 4+3 (+5MM) GLOSS BLACK / MACHINED 0230-1228 12X7 4/137 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1229 12X7 4/110 4+3 (+10MM) GLOSS BLACK 0230-1234 12X7 4/110 2+5 (-47MM) GLOSS BLACK 0230-1235 12X7 4/156 4+3 (+5MM) GLOSS BLACK 0230-1236 14x7 Gloss Black / Machined

- - 23 HL3 SIZE BOLT PATTERN OFFSET FINISH COLOR PARTS UNLIMITED PART # 14X7 4/110 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1230 14X7 4/110 2+5 (-47MM) GLOSS BLACK / MACHINED 0230-1231 14X7 4/156 4+3 (+5MM) GLOSS BLACK / MACHINED 0230-1232 14X7 4/137 4+3 (+10MM) GLOSS BLACK / MACHINED 0230-1233 14X7 4/110 4+3 (+10MM) GLOSS BLACK 0230-1237 14X7 4/110 2+5 (-47MM) GLOSS BLACK 0230-1238 14X7 4/156 4+3 (+5MM) GLOSS BLACK 0230-1239 14X7 4/137 4+3 (+10MM) GLOSS BLACK 0230-1240 14x7 Gloss Black

24 - - 2022 Popular Wheel Applications & Required Lug Nuts Can-Am Maverick X3 ‘17-22** / Can-Am Maverick Sport ‘19-22 / Can-Am Commander 1000 ‘21-22 MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL03-1137 0230-1233 0223-0218 0223-0219 HL3 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL03-1237 0230-1240 0223-0218 0223-0219 HL4 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL04-1137 0230-1247 0223-0218 0223-0219 HL4 Front/Rear 20x6.5 4/137 4+3 (+10mm) Gloss Black w/ Machined 20HL04-1137 0230-1249 0223-0218 0223-0219 HL9 Beadlock Front/Rear 14x7 4/137 4+3 (0mm) Matte Black 14HL09-1436 0230-1254 0223-0218 0223-0219 HL9 Beadlock Front/Rear 14x7 4/137 5+2 (+30mm) Matte Black 14HL09-1437 0230-1252 0223-0218 0223-0219 HL9 Beadlock Front/Rear 14x7 4/137 6+1 (+50mm) Matte Black 14HL09-1438 0230-1253 0223-0218 0223-0219 HL9 Beadlock Rear 14x10 4/137 5+5 (0mm) Matte Black 14HL09-14371 0230-1256 0223-0218 0223-0219 HL9 Beadlock Front/Rear 15x7 4/137 4+3 (0mm) Matte Black 15HL09-1436 0230-1261 0223-0218 0223-0219 HL9 Beadlock Front/Rear 15x7 4/137 5+2 (+30mm) Matte Black 15HL09-1437 0230-1259 0223-0218 0223-0219 HL9 Beadlock Front/Rear 15x7 4/137 6+1 (+50mm) Matte Black 15HL09-1438 0230-1260 0223-0218 0223-0219 HL9 Beadlock Rear 15x10 4/137 5+5 (0mm) Matte Black 15HL09-14371 0230-1263 0223-0218 0223-0219 HL9 Beadlock Front/Rear 18x7 4/137 6+1 (+45mm) Matte Black 18HL09-1438 0230-1265 0223-0218 0223-0219 HL10 Front/Rear 14x7 4/137 5+2 (+30mm) Smoke w/ Matte Black 14HL10-1637 0230-1270 0223-0218 0223-0219 HL10 Front/Rear 14x7 4/137 5+2 (+30mm) Gloss Black 14HL10-1237 0230-1273 0223-0218 0223-0219 HL10 Front/Rear 15x7 4/137 5+2 (+40mm) Gloss Black 15HL10-1237 0230-1275 0223-0218 0223-0219 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Machined w/ Gloss Black 20HL10-1137 0230-1277 0223-0218 0223-0219 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Smoke w/ Matte Black 20HL10-1637 0230-1279 0223-0218 0223-0219 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black 20HL10-1237 0230-1281 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 14x7 4/137 5+2 (+40mm) Machined 14HLA1-1737 0230-1283 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 14x7 4/137 5+2 (+40mm) Matte Black 14HLA1-1437 0230-1287 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 15x7 4/137 5+2 (+40mm) Machined 15HLA1-1737 0230-1285 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 15x7 4/137 5+2 (+40mm) Matte Black 15HLA1-1437 0230-1289 0223-0218 0223-0219 HL21 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL21-1137 0230-1290 0223-0218 0223-0219 HL21 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL21-1237 0230-1292 0223-0218 0223-0219 HL21 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 20HL21-1137 0230-1320 0223-0218 0223-0219 HL21 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black 20HL21-1237 0230-1323 0223-0218 0223-0219 HL21 Front/Rear 22x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 22HL21-1137 0230-1326 0223-0218 0223-0219 HL21 Front/Rear 22x7 4/137 4+3 (+10mm) Gloss Black 22HL21-1237 0230-1329 0223-0218 0223-0219 HL21 Front/Rear 24x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 24HL21-1137 0230-1332 0223-0218 0223-0219 HL21 Front/Rear 24x7 4/137 4+3 (+10mm) Gloss Black 24HL21-1237 0230-1335 0223-0218 0223-0219 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL22-1137 0230-1294 0223-0218 0223-0219 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL22-1237 0230-1296 0223-0218 0223-0219 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gun Metal Grey w/ Machined 14HL22-1837 0230-1298 0223-0218 0223-0219 HL23 Beadlock Front/Rear 14x7 4/137 5+2 (+38mm) Matte Black 14HL23-1437 0230-1300 0223-0218 0223-0219 HL23 Beadlock Front/Rear 14x7 4/137 5+2 (+38mm) Gun Metal Grey 14HL23-1537 0230-1302 0223-0218 0223-0219 HL23 Beadlock Front/Rear 15x7 4/137 5+2 (+38mm) Matte Black 15HL23-1437 0230-1304 0223-0218 0223-0219 HL23 Beadlock Front/Rear 15x7 4/137 5+2 (+38mm) Gun Metal Grey 15HL23-1537 0230-1306 0223-0218 0223-0219 ** Can-Am Maverick X3 must must use lug nut part # 0223-0220 (Chrome) or 0223-0221 (black)

- - 25 2022 Popular Wheel Applications & Required Lug Nuts Can-Am Maverick ‘13-19 / Can-Am Defender ‘16-22 / Can-Am Commander 800 / 1000 ‘11-20 Can-Am/Bombardier Outlander 330 / 400 / 500 / 650 / 800 ‘03-22 / Can-Am Renegade 500 / 800 / 1000 ‘08-22 MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front/Rear 12x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 12HL03-1137 0230-1229 0223-0218 0223-0219 HL3 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL03-1137 0230-1233 0223-0218 0223-0219 HL3 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL03-1237 0230-1240 0223-0218 0223-0219 HL4 Front/Rear 12x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 12HL04-1137 0230-1244 0223-0218 0223-0219 HL4 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL04-1137 0230-1247 0223-0218 0223-0219 HL4 Front/Rear 20x6.5 4/137 4+3 (+10mm) Gloss Black w/ Machined 20HL04-1137 0230-1249 0223-0218 0223-0219 HL9 Beadlock Front/Rear 14x7 4/137 4+3 (0mm) Matte Black 14HL09-1436 0230-1254 0223-0218 0223-0219 HL9 Beadlock Front/Rear 14x7 4/137 5+2 (+30mm) Matte Black 14HL09-1437 0230-1252 0223-0218 0223-0219 HL9 Beadlock Rear 14x10 4/137 5+5 (0mm) Matte Black 14HL09-14371 0230-1256 0223-0218 0223-0219 HL9 Beadlock Front/Rear 15x7 4/137 4+3 (0mm) Matte Black 15HL09-1436 0230-1261 0223-0218 0223-0219 HL9 Beadlock Front/Rear 15x7 4/137 5+2 (+30mm) Matte Black 15HL09-1437 0230-1259 0223-0218 0223-0219 HL9 Beadlock Rear 15x10 4/137 5+5 (0mm) Matte Black 15HL09-14371 0230-1263 0223-0218 0223-0219 HL9 Beadlock Front/Rear 18x7 4/137 6+1 (+45mm) Matte Black 18HL09-1438 0230-1265 0223-0218 0223-0219 HL10 Front/Rear 14x7 4/137 5+2 (+30mm) Smoke w/ Matte Black 14HL10-1637 0230-1270 0223-0218 0223-0219 HL10 Front/Rear 14x7 4/137 5+2 (+30mm) Gloss Black 14HL10-1237 0230-1273 0223-0218 0223-0219 HL10 Front/Rear 15x7 4/137 5+2 (+40mm) Gloss Black 15HL10-1237 0230-1275 0223-0218 0223-0219 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Machined w/ Gloss Black 20HL10-1137 0230-1277 0223-0218 0223-0219 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Smoke w/ Matte Black 20HL10-1637 0230-1279 0223-0218 0223-0219 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black 20HL10-1237 0230-1281 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 14x7 4/137 5+2 (+40mm) Machined 14HLA1-1737 0230-1283 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 14x7 4/137 5+2 (+40mm) Matte Black 14HLA1-1437 0230-1287 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 15x7 4/137 5+2 (+40mm) Machined 15HLA1-1737 0230-1285 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 15x7 4/137 5+2 (+40mm) Matte Black 15HLA1-1437 0230-1289 0223-0218 0223-0219 HL21 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL21-1137 0230-1290 0223-0218 0223-0219 HL21 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL21-1237 0230-1292 0223-0218 0223-0219 HL21 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 20HL21-1137 0230-1320 0223-0218 0223-0219 HL21 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black 20HL21-1237 0230-1323 0223-0218 0223-0219 HL21 Front/Rear 22x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 22HL21-1137 0230-1326 0223-0218 0223-0219 HL21 Front/Rear 22x7 4/137 4+3 (+10mm) Gloss Black 22HL21-1237 0230-1329 0223-0218 0223-0219 HL21 Front/Rear 24x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 24HL21-1137 0230-1332 0223-0218 0223-0219 HL21 Front/Rear 24x7 4/137 4+3 (+10mm) Gloss Black 24HL21-1237 0230-1335 0223-0218 0223-0219 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL22-1137 0230-1294 0223-0218 0223-0219 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL22-1237 0230-1296 0223-0218 0223-0219 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gun Metal Grey w/ Machined 14HL22-1837 0230-1298 0223-0218 0223-0219 HL23 Beadlock Front/Rear 14x7 4/137 5+2 (+38mm) Matte Black 14HL23-1437 0230-1300 0223-0218 0223-0219 HL23 Beadlock Front/Rear 14x7 4/137 5+2 (+38mm) Gun Metal Grey 14HL23-1537 0230-1302 0223-0218 0223-0219 HL23 Beadlock Front/Rear 15x7 4/137 5+2 (+38mm) Matte Black 15HL23-1437 0230-1304 0223-0218 0223-0219 HL23 Beadlock Front/Rear 15x7 4/137 5+2 (+38mm) Gun Metal Grey 15HL23-1537 0230-1306 0223-0218 0223-0219

2022 Popular Wheel Applications & Required Lug Nuts Polaris RZR Pro XP ‘20-22** (15-Inch Only) / Polaris RZR XP 1000 ‘14-22** Polaris RZR XP Turbo-S ‘18-21** (2-seater only, will not fit with 4-seater) MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 14HL03-1156 0230-1232 0223-0220 0223-0221 HL3 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black 14HL03-1256 0230-1239 0223-0220 0223-0221 HL4 Front/Rear 12x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 12HL04-1156 0230-1243 0223-0220 0223-0221 HL4 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 14HL04-1156 0230-1246 0223-0220 0223-0221 HL4 Front/Rear 20x6.5 4/156 4+3 (+10mm) Gloss Black w/ Machined 20HL04-1156 0230-1248 0223-0220 0223-0221 HL9 Beadlock Front/Rear 14x7 4/156 6+1 (+50mm) Matte Black 14HL09-1437 0230-1251 0223-0220 0223-0221 HL9 Beadlock Front/Rear 14x7 4/156 5+2 (+30mm) Matte Black 14HL09-1456 0230-1250 0223-0220 0223-0221 HL9 Beadlock Rear 14x10 4/156 5+5 (0mm) Matte Black 14HL09-14561 0230-1255 0223-0220 0223-0221 HL9 Beadlock Front/Rear 15x7 4/156 5+2 (+30mm) Matte Black 15HL09-1456 0230-1257 0223-0220 0223-0221 HL9 Beadlock Front/Rear 15x7 4/156 6+1 (+50mm) Matte Black 15HL09-1457 0230-1258 0223-0220 0223-0221 HL9 Beadlock Rear 15x10 4/156 5+5 (0mm) Matte Black 15HL09-14561 0230-1262 0223-0220 0223-0221 HL9 Beadlock Front/Rear 18x7 4/156 6+1 (+45mm) Matte Black 18HL09-1457 0230-1264 0223-0220 0223-0221 HL10 Front/Rear 14x7 4/156 5+2 (+30mm) Smoke w/ Matte Black 14HL10-1656 0230-1269 0223-0220 0223-0221 HL10 Front/Rear 14x7 4/156 5+2 (+30mm) Gloss Black 14HL10-1256 0230-1272 0223-0220 0223-0221 HL10 Front/Rear 15x7 4/156 5+2 (+40mm) Gloss Black 15HL10-1256 0230-1274 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Machined w/ Gloss Black 20HL10-1156 0230-1276 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Smoke w/ Matte Black 20HL10-1656 0230-1278 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black 20HL10-1256 0230-1280 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 14x7 4/156 5+2 (+40mm) Machined 14HLA1-1756 0230-1282 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 14x7 4/156 5+2 (+40mm) Matte Black 14HLA1-1456 0230-1286 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 15x7 4/156 5+2 (+40mm) Machined 15HLA1-1756 0230-1284 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 15x7 4/156 5+2 (+40mm) Matte Black 15HLA1-1456 0230-1288 0223-0220 0223-0221 HL21 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 14HL21-1156 0230-1291 0223-0220 0223-0221 HL21 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black 14HL21-1256 0230-1293 0223-0220 0223-0221 HL21 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 20HL21-1156 0230-1321 0223-0220 0223-0221 HL21 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black 20HL21-1256 0230-1324 0223-0220 0223-0221 HL21 Front/Rear 22x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 22HL21-1156 0230-1327 0223-0220 0223-0221 HL21 Front/Rear 22x7 4/156 4+3 (+10mm) Gloss Black 22HL21-1256 0230-1330 0223-0220 0223-0221 HL21 Front/Rear 24x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 24HL21-1156 0230-1333 0223-0220 0223-0221 HL21 Front/Rear 24x7 4/156 4+3 (+10mm) Gloss Black 24HL21-1256 0230-1336 0223-0220 0223-0221 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 14HL22-1156 0230-1295 0223-0220 0223-0221 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black 14HL22-1256 0230-1297 0223-0220 0223-0221 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gun Metal Grey w/ Machined 14HL22-1856 0230-1299 0223-0220 0223-0221 HL23 Beadlock Front/Rear 14x7 4/156 5+2 (+38mm) Matte Black 14HL23-1456 0230-1301 0223-0220 0223-0221 HL23 Beadlock Front/Rear 14x7 4/156 5+2 (+38mm) Gun Metal Grey 14HL23-1556 0230-1303 0223-0220 0223-0221 HL23 Beadlock Front/Rear 15x7 4/156 5+2 (+38mm) Matte Black 15HL23-1456 0230-1305 0223-0220 0223-0221 HL23 Beadlock Front/Rear 15x7 4/156 5+2 (+38mm) Gun Metal Grey 15HL23-1556 0230-1307 0223-0220 0223-0221 ** Must must use lug nut part # 0223-0220 (Chrome) or 0223-0221 (black) 26 - -

- - 27 2022 Popular Wheel Applications & Required Lug Nuts Polaris RZR XP Turbo ‘16-22** / Polaris RZR RS1 ‘18-21** / Polaris RZR 900 XP ‘15-19** Polaris RZR 900 Trail ‘15-22** / Polaris General 1000 EPS ‘16-22** MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front/Rear 12x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 12HL03-1156 0230-1228 0223-0220 0223-0221 HL3 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 14HL03-1156 0230-1232 0223-0220 0223-0221 HL3 Front/Rear 12x7 4/156 4+3 (+5mm) Gloss Black 12HL03-1256 0230-1236 0223-0220 0223-0221 HL3 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black 14HL03-1256 0230-1239 0223-0220 0223-0221 HL4 Front/Rear 12x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 12HL04-1156 0230-1243 0223-0220 0223-0221 HL4 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 14HL04-1156 0230-1246 0223-0220 0223-0221 HL4 Front/Rear 20x6.5 4/156 4+3 (+10mm) Gloss Black w/ Machined 20HL04-1156 0230-1248 0223-0220 0223-0221 HL9 Beadlock Front/Rear 14x7 4/156 5+2 (+30mm) Matte Black 14HL09-1456 0230-1250 0223-0220 0223-0221 HL9 Beadlock Rear 14x10 4/156 5+5 (0mm) Matte Black 14HL09-14561 0230-1255 0223-0220 0223-0221 HL9 Beadlock Front/Rear 15x7 4/156 5+2 (+30mm) Matte Black 15HL09-1456 0230-1257 0223-0220 0223-0221 HL9 Beadlock Rear 15x10 4/156 5+5 (0mm) Matte Black 15HL09-14561 0230-1262 0223-0220 0223-0221 HL9 Beadlock Front/Rear 18x7 4/156 6+1 (+45mm) Matte Black 18HL09-1457 0230-1264 0223-0220 0223-0221 HL10 Front/Rear 14x7 4/156 5+2 (+30mm) Smoke w/ Matte Black 14HL10-1656 0230-1269 0223-0220 0223-0221 HL10 Front/Rear 14x7 4/156 5+2 (+30mm) Gloss Black 14HL10-1256 0230-1272 0223-0220 0223-0221 HL10 Front/Rear 15x7 4/156 5+2 (+40mm) Gloss Black 15HL10-1256 0230-1274 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Machined w/ Gloss Black 20HL10-1156 0230-1276 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Smoke w/ Matte Black 20HL10-1656 0230-1278 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black 20HL10-1256 0230-1280 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 14x7 4/156 5+2 (+40mm) Machined 14HLA1-1756 0230-1282 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 14x7 4/156 5+2 (+40mm) Matte Black 14HLA1-1456 0230-1286 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 15x7 4/156 5+2 (+40mm) Machined 15HLA1-1756 0230-1284 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 15x7 4/156 5+2 (+40mm) Matte Black 15HLA1-1456 0230-1288 0223-0220 0223-0221 HL21 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 14HL21-1156 0230-1291 0223-0220 0223-0221 HL21 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black 14HL21-1256 0230-1293 0223-0220 0223-0221 HL21 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 20HL21-1156 0230-1321 0223-0220 0223-0221 HL21 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black 20HL21-1256 0230-1324 0223-0220 0223-0221 HL21 Front/Rear 22x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 22HL21-1156 0230-1327 0223-0220 0223-0221 HL21 Front/Rear 22x7 4/156 4+3 (+10mm) Gloss Black 22HL21-1256 0230-1330 0223-0220 0223-0221 HL21 Front/Rear 24x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 24HL21-1156 0230-1333 0223-0220 0223-0221 HL21 Front/Rear 24x7 4/156 4+3 (+10mm) Gloss Black 24HL21-1256 0230-1336 0223-0220 0223-0221 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 14HL22-1156 0230-1295 0223-0220 0223-0221 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black 14HL22-1256 0230-1297 0223-0220 0223-0221 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gun Metal Grey w/ Machined 14HL22-1856 0230-1299 0223-0220 0223-0221 HL23 Beadlock Front/Rear 14x7 4/156 5+2 (+38mm) Matte Black 14HL23-1456 0230-1301 0223-0220 0223-0221 HL23 Beadlock Front/Rear 14x7 4/156 5+2 (+38mm) Gun Metal Grey 14HL23-1556 0230-1303 0223-0220 0223-0221 HL23 Beadlock Front/Rear 15x7 4/156 5+2 (+38mm) Matte Black 15HL23-1456 0230-1305 0223-0220 0223-0221 HL23 Beadlock Front/Rear 15x7 4/156 5+2 (+38mm) Gun Metal Grey 15HL23-1556 0230-1307 0223-0220 0223-0221 ** Must must use lug nut part # 0223-0220 (Chrome) or 0223-0221 (black)

28 - - 2022 Popular Wheel Applications & Required Lug Nuts Polaris RZR 570 ‘14-15 / Polaris RZR 800 / 900XP ‘08-14 / Polaris Ranger 900XP ‘13-19** Polaris Ranger 4x4 ‘03-22 / Polaris Sportsman 335/400/450/500/600/700/800 ‘96-22 MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front/Rear 12x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 12HL03-1156 0230-1228 0223-0222 0223-0223 HL3 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 14HL03-1156 0230-1232 0223-0222 0223-0223 HL3 Front/Rear 12x7 4/156 4+3 (+5mm) Gloss Black 12HL03-1256 0230-1236 0223-0222 0223-0223 HL3 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black 14HL03-1256 0230-1239 0223-0222 0223-0223 HL4 Front/Rear 12x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 12HL04-1156 0230-1243 0223-0222 0223-0223 HL4 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 14HL04-1156 0230-1246 0223-0222 0223-0223 HL4 Front/Rear 20x6.5 4/156 4+3 (+10mm) Gloss Black w/ Machined 20HL04-1156 0230-1248 0223-0222 0223-0223 HL9 Beadlock Front/Rear 14x7 4/156 5+2 (+30mm) Matte Black 14HL09-1456 0230-1250 0223-0222 0223-0223 HL9 Beadlock Rear 14x10 4/156 5+5 (0mm) Matte Black 14HL09-14561 0230-1255 0223-0222 0223-0223 HL9 Beadlock Front/Rear 15x7 4/156 5+2 (+30mm) Matte Black 15HL09-1456 0230-1257 0223-0222 0223-0223 HL9 Beadlock Rear 15x10 4/156 5+5 (0mm) Matte Black 15HL09-14561 0230-1262 0223-0222 0223-0223 HL9 Beadlock Front/Rear 18x7 4/156 6+1 (+45mm) Matte Black 18HL09-1457 0230-1264 0223-0222 0223-0223 HL10 Front/Rear 14x7 4/156 5+2 (+30mm) Smoke w/ Matte Black 14HL10-1656 0230-1269 0223-0222 0223-0223 HL10 Front/Rear 14x7 4/156 5+2 (+30mm) Gloss Black 14HL10-1256 0230-1272 0223-0222 0223-0223 HL10 Front/Rear 15x7 4/156 5+2 (+40mm) Gloss Black 15HL10-1256 0230-1274 0223-0222 0223-0223 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Machined w/ Gloss Black 20HL10-1156 0230-1276 0223-0222 0223-0223 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Smoke w/ Matte Black 20HL10-1656 0230-1278 0223-0222 0223-0223 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black 20HL10-1256 0230-1280 0223-0222 0223-0223 HLA1 Beadlock Front/Rear 14x7 4/156 5+2 (+40mm) Machined 14HLA1-1756 0230-1282 0223-0222 0223-0223 HLA1 Beadlock Front/Rear 14x7 4/156 5+2 (+40mm) Matte Black 14HLA1-1456 0230-1286 0223-0222 0223-0223 HLA1 Beadlock Front/Rear 15x7 4/156 5+2 (+40mm) Machined 15HLA1-1756 0230-1284 0223-0222 0223-0223 HLA1 Beadlock Front/Rear 15x7 4/156 5+2 (+40mm) Matte Black 15HLA1-1456 0230-1288 0223-0222 0223-0223 HL21 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 14HL21-1156 0230-1291 0223-0222 0223-0223 HL21 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black 14HL21-1256 0230-1293 0223-0222 0223-0223 HL21 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 20HL21-1156 0230-1321 0223-0222 0223-0223 HL21 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black 20HL21-1256 0230-1324 0223-0222 0223-0223 HL21 Front/Rear 22x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 22HL21-1156 0230-1327 0223-0222 0223-0223 HL21 Front/Rear 22x7 4/156 4+3 (+10mm) Gloss Black 22HL21-1256 0230-1330 0223-0222 0223-0223 HL21 Front/Rear 24x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 24HL21-1156 0230-1333 0223-0222 0223-0223 HL21 Front/Rear 24x7 4/156 4+3 (+10mm) Gloss Black 24HL21-1256 0230-1336 0223-0222 0223-0223 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 14HL22-1156 0230-1295 0223-0222 0223-0223 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black 14HL22-1256 0230-1297 0223-0222 0223-0223 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gun Metal Grey w/ Machined 14HL22-1856 0230-1299 0223-0222 0223-0223 HL23 Beadlock Front/Rear 14x7 4/156 5+2 (+38mm) Matte Black 14HL23-1456 0230-1301 0223-0222 0223-0223 HL23 Beadlock Front/Rear 14x7 4/156 5+2 (+38mm) Gun Metal Grey 14HL23-1556 0230-1303 0223-0222 0223-0223 HL23 Beadlock Front/Rear 15x7 4/156 5+2 (+38mm) Matte Black 15HL23-1456 0230-1305 0223-0222 0223-0223 HL23 Beadlock Front/Rear 15x7 4/156 5+2 (+38mm) Gun Metal Grey 15HL23-1556 0230-1307 0223-0222 0223-0223 ** Polaris Ranger 900 XP must use lug nut part # 0223-0222 (chrome) or 0223-0223 (black)

- - 29 2022 Popular Wheel Applications & Required Lug Nuts Polaris RZR Pro-R / Turbo-R 2022 MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HLA1 Beadlock Front/Rear 15x7 5/4.5 5+2 (+40mm) Machined 15HLA1-1745 0230-1318 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 15x7 5/4.5 5+2 (+40mm) Matte Black 15HLA1-1445 0230-1319 0223-0220 0223-0221 HL21 Front/Rear 20x7 5/4.5 4+3 (+10mm) Gloss Black w/ Machined 20HL21-1145 0230-1322 0223-0220 0223-0221 HL21 Front/Rear 20x7 5/4.5 4+3 (+10mm) Gloss Black 20HL21-1245 0230-1325 0223-0220 0223-0221 HL21 Front/Rear 22x7 5/4.5 4+3 (+10mm) Gloss Black w/ Machined 22HL21-1145 0230-1328 0223-0220 0223-0221 HL21 Front/Rear 22x7 5/4.5 4+3 (+10mm) Gloss Black 22HL21-1245 0230-1331 0223-0220 0223-0221 HL21 Front/Rear 24x7 5/4.5 4+3 (+10mm) Gloss Black w/ Machined 24HL21-1145 0230-1334 0223-0220 0223-0221 HL21 Front/Rear 24x7 5/4.5 4+3 (+10mm) Gloss Black 24HL21-1245 0230-1337 0223-0220 0223-0221 Polaris Sportsman XP 550 ‘09-18 / Polaris Sportman XP 850 ‘09-18 / Polaris Sportsman XP 1000 ‘15-22 Polaris Scrambler XP 850/ XP 1000 ‘14-22 MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 14HL03-1156 0230-1232 0223-0218 0223-0219 HL3 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black 14HL03-1256 0230-1239 0223-0218 0223-0219 HL4 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 14HL04-1156 0230-1246 0223-0218 0223-0219 HL9 Beadlock Front/Rear 14x7 4/156 5+2 (+30mm) Matte Black 14HL09-1456 0230-1250 0223-0218 0223-0219 HL9 Beadlock Front/Rear 15x7 4/156 5+2 (+30mm) Matte Black 15HL09-1456 0230-1257 0223-0218 0223-0219 HL10 Front/Rear 14x7 4/156 5+2 (+30mm) Smoke w/ Matte Black 14HL10-1656 0230-1269 0223-0218 0223-0219 HL10 Front/Rear 14x7 4/156 5+2 (+30mm) Gloss Black 14HL10-1256 0230-1272 0223-0218 0223-0219 HL10 Front/Rear 15x7 4/156 5+2 (+40mm) Gloss Black 15HL10-1256 0230-1274 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 14x7 4/156 5+2 (+40mm) Machined 14HLA1-1756 0230-1282 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 14x7 4/156 5+2 (+40mm) Matte Black 14HLA1-1456 0230-1286 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 15x7 4/156 5+2 (+40mm) Machined 15HLA1-1756 0230-1284 0223-0218 0223-0219 HLA1 Beadlock Front/Rear 15x7 4/156 5+2 (+40mm) Matte Black 15HLA1-1456 0230-1288 0223-0218 0223-0219 HL21 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 14HL21-1156 0230-1291 0223-0218 0223-0219 HL21 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black 14HL21-1256 0230-1293 0223-0218 0223-0219 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 14HL22-1156 0230-1295 0223-0218 0223-0219 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black 14HL22-1256 0230-1297 0223-0218 0223-0219 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gun Metal Grey w/ Machined 14HL22-1856 0230-1299 0223-0218 0223-0219 HL23 Beadlock Front/Rear 14x7 4/156 5+2 (+38mm) Matte Black 14HL23-1456 0230-1301 0223-0218 0223-0219 HL23 Beadlock Front/Rear 14x7 4/156 5+2 (+38mm) Gun Metal Grey 14HL23-1556 0230-1303 0223-0218 0223-0219 HL23 Beadlock Front/Rear 15x7 4/156 5+2 (+38mm) Matte Black 15HL23-1456 0230-1305 0223-0218 0223-0219 HL23 Beadlock Front/Rear 15x7 4/156 5+2 (+38mm) Gun Metal Grey 15HL23-1556 0230-1307 0223-0218 0223-0219

30 - - 2022 Popular Wheel Applications & Required Lug Nuts Honda Pioneer 1000 ‘15-22 MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front/Rear 12x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 12HL03-1137 0230-1229 0223-0220 0223-0221 HL3 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL03-1137 0230-1233 0223-0220 0223-0221 HL3 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL03-1237 0230-1240 0223-0220 0223-0221 HL4 Front/Rear 12x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 12HL04-1137 0230-1244 0223-0220 0223-0221 HL4 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL04-1137 0230-1247 0223-0220 0223-0221 HL4 Front/Rear 20x6.5 4/137 4+3 (+10mm) Gloss Black w/ Machined 20HL04-1137 0230-1249 0223-0220 0223-0221 HL9 Beadlock Front/Rear 14x7 4/137 5+2 (+30mm) Matte Black 14HL09-1437 0230-1252 0223-0220 0223-0221 HL9 Beadlock Front/Rear 15x7 4/137 5+2 (+30mm) Matte Black 15HL09-1437 0230-1259 0223-0220 0223-0221 HL10 Front/Rear 14x7 4/137 5+2 (+30mm) Smoke w/ Matte Black 14HL10-1637 0230-1270 0223-0220 0223-0221 HL10 Front/Rear 14x7 4/137 5+2 (+30mm) Gloss Black 14HL10-1237 0230-1273 0223-0220 0223-0221 HL10 Front/Rear 15x7 4/137 5+2 (+40mm) Gloss Black 15HL10-1237 0230-1275 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Machined w/ Gloss Black 20HL10-1137 0230-1277 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Smoke w/ Matte Black 20HL10-1637 0230-1279 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black 20HL10-1237 0230-1281 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 14x7 4/137 5+2 (+40mm) Machined 14HLA1-1737 0230-1283 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 14x7 4/137 5+2 (+40mm) Matte Black 14HLA1-1437 0230-1287 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 15x7 4/137 5+2 (+40mm) Machined 15HLA1-1737 0230-1285 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 15x7 4/137 5+2 (+40mm) Matte Black 15HLA1-1437 0230-1289 0223-0220 0223-0221 HL21 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL21-1137 0230-1290 0223-0220 0223-0221 HL21 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL21-1237 0230-1292 0223-0220 0223-0221 HL21 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 20HL21-1137 0230-1320 0223-0220 0223-0221 HL21 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black 20HL21-1237 0230-1323 0223-0220 0223-0221 HL21 Front/Rear 22x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 22HL21-1137 0230-1326 0223-0220 0223-0221 HL21 Front/Rear 22x7 4/137 4+3 (+10mm) Gloss Black 22HL21-1237 0230-1329 0223-0220 0223-0221 HL21 Front/Rear 24x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 24HL21-1137 0230-1332 0223-0220 0223-0221 HL21 Front/Rear 24x7 4/137 4+3 (+10mm) Gloss Black 24HL21-1237 0230-1335 0223-0220 0223-0221 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL22-1137 0230-1294 0223-0220 0223-0221 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL22-1237 0230-1296 0223-0220 0223-0221 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gun Metal Grey w/ Machined 14HL22-1837 0230-1298 0223-0220 0223-0221 HL23 Beadlock Front/Rear 14x7 4/137 5+2 (+38mm) Matte Black 14HL23-1437 0230-1300 0223-0220 0223-0221 HL23 Beadlock Front/Rear 14x7 4/137 5+2 (+38mm) Gun Metal Grey 14HL23-1537 0230-1302 0223-0220 0223-0221 HL23 Beadlock Front/Rear 15x7 4/137 5+2 (+38mm) Matte Black 15HL23-1437 0230-1304 0223-0220 0223-0221 HL23 Beadlock Front/Rear 15x7 4/137 5+2 (+38mm) Gun Metal Grey 15HL23-1537 0230-1306 0223-0220 0223-0221

- - 31 2022 Popular Wheel Applications & Required Lug Nuts Honda Big Red MUV ‘09-15 / Honda Pioneer 500 / 700 ‘14-22 MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front/Rear 12x7 4/110 4+3 (+10mm) Gloss Black w/ Machined 12HL03-1110 0230-1226 0223-0220 0223-0221 HL3 Front/Rear 14x7 4/110 4+3 (+10mm) Gloss Black w/ Machined 14HL03-1110 0230-1230 0223-0220 0223-0221 HL3 Front/Rear 12x7 4/110 4+3 (+10mm) Gloss Black 12HL03-1210 0230-1234 0223-0220 0223-0221 HL3 Front/Rear 14x7 4/110 4+3 (+10mm) Gloss Black 14HL03-1210 0230-1237 0223-0220 0223-0221 HL4 Front/Rear 12x7 4/110 4+3 (+10mm) Gloss Black w/ Machined 12HL04-1110 0230-1241 0223-0220 0223-0221 HL4 Front/Rear 14x7 4/110 4+3 (+10mm) Gloss Black w/ Machined 14HL04-1110 0230-1245 0223-0220 0223-0221 HL10 Front/Rear 12x7 4/110 4+3 (+10mm) Machined w/ Gloss Black 12HL10-1110 0230-1266 0223-0220 0223-0221 HL10 Front/Rear 14x7 4/110 5+2 (+30mm) Smoke w/ Matte Black 14HL10-1610 0230-1268 0223-0220 0223-0221 HL10 Front/Rear 14x7 4/110 5+2 (+30mm) Gloss Black 14HL10-1210 0230-1271 0223-0220 0223-0221 Honda 500 Rubicon 4x4 ‘15-22 (IRS) / Honda 650/700 Rincon 4x4 ‘02-22 (IRS) / Honda 420 Rancher AT ‘09-22 (IRS) MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front/Rear 12x7 4/110 4+3 (+10mm) Gloss Black w/ Machined 12HL03-1110 0230-1226 0223-0218 0223-0219 HL3 Front/Rear 14x7 4/110 4+3 (+10mm) Gloss Black w/ Machined 14HL03-1110 0230-1230 0223-0218 0223-0219 HL3 Front/Rear 12x7 4/110 4+3 (+10mm) Gloss Black 12HL03-1210 0230-1234 0223-0218 0223-0219 HL3 Front/Rear 14x7 4/110 4+3 (+10mm) Gloss Black 14HL03-1210 0230-1237 0223-0218 0223-0219 HL4 Front/Rear 12x7 4/110 4+3 (+10mm) Gloss Black w/ Machined 12HL04-1110 0230-1241 0223-0218 0223-0219 HL4 Front/Rear 14x7 4/110 4+3 (+10mm) Gloss Black w/ Machined 14HL04-1110 0230-1245 0223-0218 0223-0219 HL10 Front/Rear 12x7 4/110 4+3 (+10mm) Machined w/ Gloss Black 12HL10-1110 0230-1266 0223-0218 0223-0219 HL10 Front/Rear 14x7 4/110 5+2 (+30mm) Smoke w/ Matte Black 14HL10-1610 0230-1268 0223-0218 0223-0219 HL10 Front/Rear 14x7 4/110 5+2 (+30mm) Gloss Black 14HL10-1210 0230-1271 0223-0218 0223-0219 Honda 300 4x4 ‘89-00 (Straight-Axle) / Honda 350 Rancher S-ES 4x4 ‘00-06 (Straight-Axle) Honda 400/420 Rancher 4x4 ‘04-22 (Straight-Axle) / Honda 400 Foreman 4x4 ‘96-06 (Straight-Axle) Honda 450/500 Foreman S-ES 4x4 ‘98-22 (Straight-Axle) / Honda 500 Rubicon 4x4 ‘01-10 (Straight-Axle) MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front 12x7 4/110 4+3 (+10mm) Gloss Black w/ Machined 12HL03-1110 0230-1226 0223-0218 0223-0219 HL3 Rear 12x7 4/110 2+5 (-47mm) Gloss Black w/ Machined 12HL03-1111 0230-1227 0223-0218 0223-0219 HL3 Front 14x7 4/110 4+3 (+10mm) Gloss Black w/ Machined 14HL03-1110 0230-1230 0223-0218 0223-0219 HL3 Rear 14x7 4/110 2+5 (-47mm) Gloss Black w/ Machined 14HL03-1111 0230-1231 0223-0218 0223-0219 HL3 Front 12x7 4/110 4+3 (+10mm) Gloss Black 12HL03-1210 0230-1234 0223-0218 0223-0219 HL3 Rear 12x7 4/110 2+5 (-47mm) Gloss Black 12HL03-1211 0230-1235 0223-0218 0223-0219 HL3 Front 14x7 4/110 4+3 (+10mm) Gloss Black 14HL03-1210 0230-1237 0223-0218 0223-0219 HL3 Rear 14x7 4/110 2+5 (-47mm) Gloss Black 14HL03-1211 0230-1238 0223-0218 0223-0219 HL4 Front 12x7 4/110 4+3 (+10mm) Gloss Black w/ Machined 12HL04-1110 0230-1241 0223-0218 0223-0219 HL4 Rear 12x7 4/110 2+5 (-47mm) Gloss Black w/ Machined 12HL04-1111 0230-1242 0223-0218 0223-0219 HL10 Front 12x7 4/110 4+3 (+10mm) Machined w/ Gloss Black 12HL10-1110 0230-1266 0223-0218 0223-0219 HL10 Rear 12x7 4/110 2+5 (-47mm) Machined w/ Gloss Black 12HL10-1111 0230-1267 0223-0218 0223-0219

32 - - 2022 Popular Wheel Applications & Required Lug Nuts Honda Talon ‘19-22 MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL9 Beadlock Front 15x7 4/137 5+2 (+30mm) Matte Black 15HL09-1437 0230-1259 0223-0220 0223-0221 HL9 Beadlock Front 15x7 4/137 6+1 (+50mm) Matte Black 15HL09-1438 0230-1260 0223-0220 0223-0221 HL9 Beadlock Rear 15x7 4/137 4+3 (0mm) Matte Black 15HL09-1436 0230-1261 0223-0220 0223-0221 HL9 Beadlock Rear 15x10 4/137 5+5 (0mm) Matte Black 15HL09-14371 0230-1263 0223-0220 0223-0221 HL9 Beadlock Front/Rear 18x7 4/137 6+1 (+45mm) Matte Black 18HL09-1438 0230-1265 0223-0220 0223-0221 HL10 Front/Rear 15x7 4/137 5+2 (+40mm) Gloss Black 15HL10-1237 0230-1275 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Machined w/ Gloss Black 20HL10-1137 0230-1277 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Smoke w/ Matte Black 20HL10-1637 0230-1279 0223-0220 0223-0221 HL10 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black 20HL10-1237 0230-1281 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 15x7 4/137 5+2 (+40mm) Machined 15HLA1-1737 0230-1285 0223-0220 0223-0221 HLA1 Beadlock Front/Rear 15x7 4/137 5+2 (+40mm) Matte Black 15HLA1-1437 0230-1289 0223-0220 0223-0221 HL21 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 20HL21-1137 0230-1320 0223-0220 0223-0221 HL21 Front/Rear 20x7 4/137 4+3 (+10mm) Gloss Black 20HL21-1237 0230-1323 0223-0220 0223-0221 HL21 Front/Rear 22x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 22HL21-1137 0230-1326 0223-0220 0223-0221 HL21 Front/Rear 22x7 4/137 4+3 (+10mm) Gloss Black 22HL21-1237 0230-1329 0223-0220 0223-0221 HL21 Front/Rear 24x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 24HL21-1137 0230-1332 0223-0220 0223-0221 HL21 Front/Rear 24x7 4/137 4+3 (+10mm) Gloss Black 24HL21-1237 0230-1335 0223-0220 0223-0221 HL23 Beadlock Front/Rear 15x7 4/137 5+2 (+38mm) Matte Black 15HL23-1437 0230-1304 0223-0220 0223-0221 HL23 Beadlock Front/Rear 15x7 4/137 5+2 (+38mm) Gun Metal Grey 15HL23-1537 0230-1306 0223-0220 0223-0221 Kawasaki Teryx 750 ‘08-22 / Kawasaki Mule 2500 / 3000 / 4000 Series MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front/Rear 12x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 12HL03-1137 0230-1229 0223-0224 0223-0225 HL3 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL03-1137 0230-1233 0223-0224 0223-0225 HL3 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL03-1237 0230-1240 0223-0224 0223-0225 HL4 Front/Rear 12x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 12HL04-1137 0230-1244 0223-0224 0223-0225 HL4 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL04-1137 0230-1247 0223-0224 0223-0225 HL9 Beadlock Front/Rear 14x7 4/137 4+3 (0mm) Matte Black 14HL09-1436 0230-1254 0223-0224 0223-0225 HL9 Beadlock Rear 15x7 4/137 4+3 (0mm) Matte Black 15HL09-1436 0230-1261 0223-0224 0223-0225 HL21 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL21-1137 0230-1290 0223-0224 0223-0225 HL21 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL21-1237 0230-1292 0223-0224 0223-0225 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black w/ Machined 14HL22-1137 0230-1294 0223-0224 0223-0225 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gloss Black 14HL22-1237 0230-1296 0223-0224 0223-0225 HL22 Front/Rear 14x7 4/137 4+3 (+10mm) Gun Metal Grey w/ Machined 14HL22-1837 0230-1298 0223-0224 0223-0225 HL23 Beadlock Front/Rear 14x7 4/137 5+2 (+38mm) Matte Black 14HL23-1437 0230-1300 0223-0224 0223-0225 HL23 Beadlock Front/Rear 14x7 4/137 5+2 (+38mm) Gun Metal Grey 14HL23-1537 0230-1302 0223-0224 0223-0225 HL23 Beadlock Front/Rear 15x7 4/137 5+2 (+38mm) Matte Black 15HL23-1437 0230-1304 0223-0224 0223-0225 HL23 Beadlock Front/Rear 15x7 4/137 5+2 (+38mm) Gun Metal Grey 15HL23-1537 0230-1306 0223-0224 0223-0225

- - 33 2022 Popular Wheel Applications & Required Lug Nuts Kawasaki KRX 1000 ‘20-22 (15-inch & larger diameter wheels only)** / Kawasaki Mule PRO-FXT ‘14-22 (6+1 offset wheels will not fit)** MAKE/MODEL SIZE BOLT PATTERN OFFSET FINISH HIGH LIFTER PART# P/U PART# CHROME LUG NUT BLACK LUG NUT HL3 Front/Rear 12x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 12HL03-1156 0230-1228 0223-0224 0223-0225 HL3 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 14HL03-1156 0230-1232 0223-0224 0223-0225 HL3 Front/Rear 12x7 4/156 4+3 (+5mm) Gloss Black 12HL03-1256 0230-1236 0223-0224 0223-0225 HL3 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black 14HL03-1256 0230-1239 0223-0224 0223-0225 HL4 Front/Rear 12x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 12HL04-1156 0230-1243 0223-0224 0223-0225 HL4 Front/Rear 14x7 4/156 4+3 (+5mm) Gloss Black w/ Machined 14HL04-1156 0230-1246 0223-0224 0223-0225 HL4 Front/Rear 20x6.5 4/156 4+3 (+10mm) Gloss Black w/ Machined 20HL04-1156 0230-1248 0223-0224 0223-0225 HL9 Beadlock Front/Rear 14x7 4/156 5+2 (+30mm) Matte Black 14HL09-1456 0230-1250 0223-0224 0223-0225 HL9 Beadlock Front/Rear 15x7 4/156 5+2 (+30mm) Matte Black 15HL09-1456 0230-1257 0223-0224 0223-0225 HL10 Front/Rear 14x7 4/156 5+2 (+30mm) Smoke w/ Matte Black 14HL10-1656 0230-1269 0223-0224 0223-0225 HL10 Front/Rear 14x7 4/156 5+2 (+30mm) Gloss Black 14HL10-1256 0230-1272 0223-0224 0223-0225 HL10 Front/Rear 15x7 4/156 5+2 (+40mm) Gloss Black 15HL10-1256 0230-1274 0223-0224 0223-0225 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Machined w/ Gloss Black 20HL10-1156 0230-1276 0223-0224 0223-0225 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Smoke w/ Matte Black 20HL10-1656 0230-1278 0223-0224 0223-0225 HL10 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black 20HL10-1256 0230-1280 0223-0224 0223-0225 HLA1 Beadlock Front/Rear 14x7 4/156 5+2 (+40mm) Machined 14HLA1-1756 0230-1282 0223-0224 0223-0225 HLA1 Beadlock Front/Rear 14x7 4/156 5+2 (+40mm) Matte Black 14HLA1-1456 0230-1286 0223-0224 0223-0225 HLA1 Beadlock Front/Rear 15x7 4/156 5+2 (+40mm) Machined 15HLA1-1756 0230-1284 0223-0224 0223-0225 HLA1 Beadlock Front/Rear 15x7 4/156 5+2 (+40mm) Matte Black 15HLA1-1456 0230-1288 0223-0224 0223-0225 HL21 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 14HL21-1156 0230-1291 0223-0224 0223-0225 HL21 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black 14HL21-1256 0230-1293 0223-0224 0223-0225 HL21 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 20HL21-1156 0230-1321 0223-0224 0223-0225 HL21 Front/Rear 20x7 4/156 4+3 (+10mm) Gloss Black 20HL21-1256 0230-1324 0223-0224 0223-0225 HL21 Front/Rear 22x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 22HL21-1156 0230-1327 0223-0224 0223-0225 HL21 Front/Rear 22x7 4/156 4+3 (+10mm) Gloss Black 22HL21-1256 0230-1330 0223-0224 0223-0225 HL21 Front/Rear 24x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 24HL21-1156 0230-1333 0223-0224 0223-0225 HL21 Front/Rear 24x7 4/156 4+3 (+10mm) Gloss Black 24HL21-1256 0230-1336 0223-0224 0223-0225 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black w/ Machined 14HL22-1156 0230-1295 0223-0224 0223-0225 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gloss Black 14HL22-1256 0230-1297 0223-0224 0223-0225 HL22 Front/Rear 14x7 4/156 4+3 (+10mm) Gun Metal Grey w/ Machined 14HL22-1856 0230-1299 0223-0224 0223-0225 HL23 Beadlock Front/Rear 14x7 4/156 5+2 (+38mm) Matte Black 14HL23-1456 0230-1301 0223-0224 0223-0225 HL23 Beadlock Front/Rear 14x7 4/156 5+2 (+38mm) Gun Metal Grey 14HL23-1556 0230-1303 0223-0224 0223-0225 HL23 Beadlock Front/Rear 15x7 4/156 5+2 (+38mm) Matte Black 15HL23-1456 0230-1305 0223-0224 0223-0225 HL23 Beadlock Front/Rear 15x7 4/156 5+2 (+38mm) Gun Metal Grey 15HL23-1556 0230-1307 0223-0224 0223-0225 ** Must use lug nut part # 0223-0224 (chrome) or 0223-0225 (black)
